This is a newly manufactured, high-quality twin-barrel downdraft carburetor of the fajs 32/36 DGV type, equipped with a manual (cable-operated) choke. This carburetor platform is globally renowned as one of the most reliable and versatile upgrades for four-cylinder automotive engines from the 1960s, 70s, and 80s. Thanks to its progressive design – where the smaller primary barrel (32 mm) handles idling and economical cruising, while the larger secondary barrel (36 mm) opens mechanically under wide-open throttle – it delivers an ideal balance between optimized fuel economy and increased peak power.

The manual choke gives the driver complete control over cold starts without relying on troublesome electronics or bimetallic springs, making this design exceptionally reliable and highly popular for street performance, vintage rallying, and historic motorsport.

Common applications and conversions:

• Excellent replacement or upgrade carburetor for Volvo B18, B20, B21, and B23 engines
• Highly popular on Ford Kent and Pinto engines (Cortina, Escort, Taunus, Capri)
• Suitable for a wide range of other classic four-cylinder engines from Opel, VW, and collectibles

Technical specifications:

• Type: Two-barrel progressive downdraft carburetor
• Choke system: Manual choke (cable-controlled)
• Barrel size: 32 mm primary / 36 mm secondary
• Mounting flange: Standard DGV series bolt pattern (approx. 93 x 47 mm c/c)

Originalbestyckning (Port 1 / Port 2):

Redervdelar och sprängskiss till 32/36DGV  <- Klicka här ->

Vanliga tillbehör:

• Luftfilter: Art.nr 6032
• Isolerpackning: Art.nr 39150.000
• Monteringssats: Art.nr 136

Important information: The carburetor is delivered with a standard factory jetting configuration suitable for baseline startups and initial driving. For optimal performance, maximum power, and the best fuel economy, we always recommend fine-tuning and re-jetting the carburetor specifically to match your engine's unique build and wear. Complete your installation by pairing it with a suitable intake manifold, throttle cable kit, and sports air filter.
